Surface Mounting Emergency Downlight 100-347VAC Bluetooth Mesh 7W 1200lm 1.5 Hours Operation ETL Lisited

LPV-LD02BT

> The minimalist aesthetic of the external hanging design can be matched with any space decoration style
> With bluetooth connected to phone or computer for settings and status checking
> Two adjustable angles and high-efficiency lamp head assemblies allow for adjustable lighting areas
> Equipped with high-quality lithium batteries, offering a longer service life
> Provides emergency lighting of 7W 1200lm for at least 90 minutes during power outages
> The PC housing certified with UL V0 fire and flame retardant certification
> Best choice for emergency lighting in hospitals, shopping malls, offices, airports, and shops.

Quantity:

Contact Now

add to cart

Company Name

Phone

Country

Message Content

KEY FEATURES

Lamp heads can be adjusted from 0 to 15 degrees

1.5 Hours emergency illumination operation

Oval and square panel selection

Built-in LED status indicator and test button

Monthly 30 secondes and annual 1.5H self-test

Long-life, maintenance-free lithium battery

Flame retardant, impact resistant thermoplastic

Meet ETL certification

SPECIFICATIONS

Model:LPU-LA01BT

Voltage:100-347VAC 50/60Hz

Mount Type:Celling

Battery:LiFePO4

Conformity:ETL

Test Mode:Auto / bluetooth

Product Type:Emergency led downlight

Light Emission:Standard

Power:7W

Luminous Flux:1200lm

Emergency Time:≥ 3 Hours

Warranty:5 Years

SELF TEST MODE

The integrated Self-Test/Diagnostic circuitry will automatically conducts monthly 30 seconds and annual 90 minutes test to verify proper emergency capability per Life Safety Code requirements. NFPA 101 Life Safety Code Outlines the following schedule:

Check battery, lamp ,charge board and transfer fault all the time.
Monthly- During AC mode, the fixture conducts a 30 seconds self-discharge test every 30 days.
Annually- During AC mode, the fixture conducts a 90 minutes self-discharge test every 365 days.

TEST BUTTON

Explain	Function
Press once within 2 seconds	Run 10 seconds duration test
Press twice within 2 seconds	Run 30 seconds duration test
Press thrice within 2 seconds	Run 90 minutes duration test
Press once and wait >2S then press again	Light turned off. Indicator will turn green and back to charging mode
Under emergency mode, Long press the test button for >3s	Turn off the light

NOTE: The manual test function needs to connect the battery and plug in the AC power for use.

INDICATOR

Explain	Function
Slow Flash with green color	Discharging/Emergency mode
With green color all the time	Charging battery
The indicator light is off	The battery is fully charged
Fast Flash with green color	Failure

NOTE: When the fault is cleared, long press the test button for 2 seconds, The led indicator will turn green and the fixture is back to normal.
