UL 924 LED Emergency Driver 170VDC 40W for UFO High Bay Light
EMUFO-II
> UL Listed for US and CANADA
> Low energy consumption CEC Title20 compliance
> 90 Minutes emergency illumination operation
> Long-life, maintenance-free lithium battery
> High output voltage
> Constant output power
> For wiring to the led driver's AC input
> Over Temperature/Over Charge/Over Discharge Protection
> Low energy consumption CEC Title20 compliance
> 90 Minutes emergency illumination operation
> Long-life, maintenance-free lithium battery
> High output voltage
> Constant output power
> For wiring to the led driver's AC input
> Over Temperature/Over Charge/Over Discharge Protection
Quantity:
KEY FEATURES
Listed to UL924 and tested to CSA C22.2
Low energy consumption CEC Title20 compliance
High output voltage
Constant output power
Monthly 3 minutes and Annual 90 minutes self-test
Long-life, maintenance-free lithium battery
Over Temperature/ChargeDischarge/Protection
For wiring to the led driver's AC input
SPECIFICATIONS
Model:EMUFO-II
Output Voltage:170VDC
Emergency Power:25W / 40W
Discharge Time:1.5Hours
Battery:Li-ion
Weight:3.96 lbs(1.8kg) max
Warranty:5 Years
Input Voltage:100~347Vac,50/60Hz
Input Current:200mA max
Recharge Power:12W max
Recharge Time:24hours
Emergency Time:≥ 1.5H
Ambien Temp:32~122°F(0~50°C)
Surge Protection: Live-Neutral 3KV
ORDER GUIDE
| Model | Emergency Power | Output Voltage |
|---|---|---|
| EMUFO-25170-YY II | 25 Watts(Constant) | 170VDC |
| EMUFO-40170-YY II | 40 Watts(Constant) | 170VDC |
CAUTION:The unit of EMUFO-25170-YYⅡ/EMUFO-40170-YYⅡ for led lamp less than 320W (When the fixture dim to the minimum, the power needs to be less than that of emergency led driver)
SELF TEST MODE
The integrated Self-Diagnostic circuitry will automatically conduct monthly 30-second and annual 90-minute tests to verify proper
emergency capability per Life Safety Code requirements. NFPA 101, Life Safety Code Outlines the following schedule:
• Monthly- During AC mode, the system conducts a (30) seconds self-discharge test of the emergency led driver every 30 days, and automatically restore to normal charging after (30) seconds discharged.
• Annually- During AC mode, the system conducts a (90) minutes self-discharge test of the emergency led driver every 365 days. And automatically restore to normal charging after fully discharged.
