UL Listed Recessed Emergency lighting 7W 1200lm 90 Minutes Operation for Commercial and Business

LPU-LA01

> The LPV-LA01 provide a flush, recessed, ceiling mount emergency lighting unit
> Two adjustable, low-profile optical assemblies adjust the lighting area
> Equipped with high-quality lithium batteries, offering a longer service life
> Provides at least 90 minutes of 7W 1200lm emergency lighting
> Rrectangular and oval trim plates optional to complement any design aesthetic
> The PC housing certified with UL V0 fire and flame retardant certification
> best choice for emergency lighting in hospitals, shopping malls, offices, airports, and shops

Quantity:

Contact Now

add to cart

Company Name

Phone

Country

Message Content

KEY FEATURES

High efficiency 170lm/W, Max 1200lm

90 Minutes emergency illumination operation

Oval and square panel selection

Built-in LED status indicator and test button

Monthly 3 minutes and Annual 90 minutes self-test

Long-life, maintenance-free lithium battery

Flame retardant, impact resistant thermoplastic

Meet ETL certification, NFPA 101 Life Safety Code

SPECIFICATIONS

Model:LPU-LA01

Voltage:100-347VAC 50/60Hz

Mount Type:Celling / Recessed

Battery:LiFePO4 9.6V

Conformity:ETL

Test Mode:Auto / Bluetooth

Product Type:Emergency led downlight

Light Emission:Standard

Power:6W / 7W

Luminous Flux:800lm / 1200lm

Emergency Time:≥ 1.5H

Warranty:5 Years

ORDER GUIDE

Model	Input Voltage	Mounting	Power	Lumens	EM Time	Test Mode
LPV-LA01-6W	100-347VAC	Recessed	6W	800lm@5000K	≥1H/2H/3H	AT / BT
LPV-LA01-7W	100-347VAC	Recessed	7W	1200lm@5000K	≥1H/2H/3H	AT / BT

Test mode explain: MT=Manual Test, AT=Auto Test, DALI=DALI Test, BT=Bluetooth Wireless Test.

SELF TEST MODE

The integrated Self-Test/Diagnostic circuitry will automatically conducts monthly 30 seconds and annual 90 minutes test to verify proper emergency capability per Life Safety Code requirements. NFPA 101 Life Safety Code Outlines the following schedule:

Check battery, lamp ,charge board and transfer fault all the time.
Monthly- During AC mode, the fixture conducts a 30 seconds self-discharge test every 30 days.
Annually- During AC mode, the fixture conducts a 90 minutes self-discharge test every 365 days.

TEST BUTTON

Explain	Function
Press once within 2 seconds	Run 10 seconds duration test
Press twice within 2 seconds	Run 30 seconds duration test
Press thrice within 2 seconds	Run 90 minutes duration test
Press once and wait >2S then press again	Light turned off. Indicator will turn green and back to charging mode
Under emergency mode, Long press the test button for >3s	Turn off the light

NOTE: The manual test function needs to connect the battery and plug in the AC power for use.

INDICATOR

Explain	Function
Slow Flash with green color	Discharging/Emergency mode
With green color all the time	Charging battery
The indicator light is off	The battery is fully charged
Fast Flash with green color	Failure

NOTE: When the fault is cleared, long press the test button for 2 seconds, The led indicator will turn green and the fixture is back to normal.
