UL 924 LED Emergency Driver 25-230VDC Battery Backup
EMAXXYY
> UL Listed for US and CANADA
> Low energy consumption CEC Title20 compliance
> 90 Minutes emergency illumination operation
> Long-life, maintenance-free lithium battery
> High output voltage
> Constant output power
> For wiring to the led driver's AC input
> Over Temperature/Over Charge/Over Discharge Protection
> Low energy consumption CEC Title20 compliance
> 90 Minutes emergency illumination operation
> Long-life, maintenance-free lithium battery
> High output voltage
> Constant output power
> For wiring to the led driver's AC input
> Over Temperature/Over Charge/Over Discharge Protection
Quantity:
KEY FEATURES
Listed to UL924 and tested to CSA C22.2
Low energy consumption CEC Title20 compliance
High output voltage
Constant output power
Monthly 3 minutes and Annual 90 minutes self-test
Long-life, maintenance-free lithium battery
Over Temperature/ChargeDischarge/Protection
For wiring to the led driver's AC input
SPECIFICATIONS
Model:EMAXXFY
Output Voltage:25-230VDC
Emergency Power:30W max
Discharge Time:1.5Hours
Battery:Li-ion
Weight:2.36 lbs(1.07kg) max
Warranty:5 Years
Input Voltage:100~347VAC,50/60Hz
Input Current:100mA max
Recharge Power:7W max
Recharge Time:24hours
Emergency Time:≥ 1.5H
Ambien Temp:32~122°F(0~50°C)
Surge Protection: Live-Neutral 3KV
ORDER GUIDE
| Model | Emergency Power | Output Volatge |
|---|---|---|
| EMA08YY-050, EMA08YY-080, EMA08YY-155, EMA08YY-230 | 8 Watts(Constant) | / |
| EMA15YY-050, EMA15YY-080, EMA15YY-155, EMA15YY-230 | 15 Watts(Constant) | / |
| EMA30YY-050, EMA30YY-080, EMA30YY-155, EMA30YY-230 | 30 Watts(Constant) | / |
NOTE: Power of the EMAXXYY selected must not exceed the power of the A.C. driver from led fixture.
The EMAXXYY-Y-050 can be used with most led loads that operate at 25-50VDC
The EMAXXYY-Y-080 can be used with most led loads that operate at 51-80VDC
The EMAXXYY-Y-155 can be used with most led loads that operate at 81-155VDC
The EMAXXYY-Y-230 can be used with most led loads that operate at 156-230VDC
The EMAXXYY-Y-050 can be used with most led loads that operate at 25-50VDC
The EMAXXYY-Y-080 can be used with most led loads that operate at 51-80VDC
The EMAXXYY-Y-155 can be used with most led loads that operate at 81-155VDC
The EMAXXYY-Y-230 can be used with most led loads that operate at 156-230VDC
SELF TEST MODE
The integrated Self-Diagnostic circuitry will automatically conduct monthly 30-second and annual 90-minute tests to verify proper
emergency capability per Life Safety Code requirements. NFPA 101, Life Safety Code Outlines the following schedule:
• Monthly- During AC mode, the system conducts a (30) seconds self-discharge test of the emergency led driver every 30 days, and automatically restore to normal charging after (30) seconds discharged.
• Annually- During AC mode, the system conducts a (90) minutes self-discharge test of the emergency led driver every 365 days. And automatically restore to normal charging after fully discharged.
